Thyroid storm rescued by extracorporeal membrane oxygenation support, plasmapheresis and thyroidectomy: a case report
Case Report

Thyroid storm rescued by extracorporeal membrane oxygenation support, plasmapheresis and thyroidectomy: a case report

Irene Me Jin Wong1^, Ju Yee Lim2, Jonathan Teow Koon Goh3, Qiao Li Tan4, Chee Kiang Tay4^

1Department of Surgical Intensive Care, Singapore General Hospital, Singapore, Singapore; 2Post Acute and Continuing Care Team, Outram Community Hospital, Singapore, Singapore; 3Singhealth Respiratory Medicine Senior Residency, Singapore, Singapore; 4Department of Respiratory and Critical Care Medicine, Singapore General Hospital, Singapore, Singapore

^ORCID: Irene Mei Jin Wong 0000-0002-4375-3665, Chee Kiang Tay 0000-0002-8122-6559.

Correspondence to: Irene Mei Jin Wong. Department of Surgical Intensive Care, Singapore General Hospital, Outram Road, 169608 Singapore. Email: irene.wong.m.j@singhealth.com.sg.

Abstract: We present a complex case of a 44-year-old Chinese man who presented with thyroid storm and cardiovascular collapse requiring multi organ support in the intensive care unit. Our patient presented to the emergency department with dyspnoea. He was found to be in atrial fibrillation with rapid ventricular response. Thyroid function test was compatible with thyrotoxicosis. He deteriorated rapidly and suffered pulseless electrical activity cardiac arrest. Cardiopulmonary resuscitation was promptly started and return of spontaneous circulation was achieved. Unfortunately, the patient sustained three further episodes of pulseless electrical activity while the extracorporeal membrane oxygenation team from the referral centre was en-route. He was then established on veno-arterial extracorporeal membrane oxygenation for safe transfer to a specialist centre. The patient underwent urgent plasmapheresis and thyroidectomy for the management of thyroid storm. He was successfully weaned off extracorporeal support and liberated from mechanical ventilation. To our knowledge, this is the first case reported of the successful use of both arterio-venous extracorporeal membrane oxygenation, and plasmapheresis as a bridge to total thyroidectomy for control of thyrotoxicosis. This case illustrates the importance of expediency in instituting the stepwise treatment modalities in a time-sensitive manner leading to a favourable outcome.

Keywords: Thyroid crisis; extracorporeal membrane oxygenation (ECMO); plasma exchange; thyroidectomy; case report


Received: 04 October 2020; Accepted: 27 December 2020; Published: 25 April 2021.

doi: 10.21037/jeccm-20-147


Introduction

A 44-year-old Chinese man presented with thyroid storm and circulatory collapse requiring multiorgan and extracorporeal life support in the intensive care unit. Extracorporeal membrane oxygenation (ECMO) is now a well-established, lifesaving option for patients with acute cardiorespiratory failure as described in the Extracorporeal Life Support Organization Guidelines in 2017 (1). Thus far, there have been several case reports and case series describing the successful use of ECMO in patients with thyrotoxicosis. As early as 2011, a case series (2) described the survival of 3 out of 4 patients in which ECMO was used as a rescue for thyrotoxicosis induced cardiovascular collapse. Another case series published in 2015 (3) described the use of ECMO in 5 patients with thyroid storm, out of which 3 survived. A case series published in 2018 (4) described 14 cases of the use of ECMO for thyrotoxicosis induced cardiomyopathy of which 11 patients survived. 3 other case reports described the successful use of ECMO as a rescue therapy for thyrotoxicosis induced cardiogenic shock and haemodynamic collapse (5-7). One case report described the use of ECMO with plasma exchange (8). We describe the successful use of both VA-ECMO, plasma exchange as a bridge to total thyroidectomy for control of thyrotoxicosis in a patient with thyroid storm complicated by multiorgan failure. To our knowledge, this is the first report combining veno-arterial extracorporeal membrane oxygenation, plasmapheresis, and total thyroidectomy to control life-threatening thyrotoxicosis. We present the following case in accordance with the CARE reporting checklist (available at http://dx.doi.org/10.21037/jeccm-20-147).


Case presentation

A 44-year-old Chinese man with recently diagnosed Grave’s Disease presented to the emergency department with dyspnoea. On arrival, he was pyrexial, tachycardic at 199 beats/min, and normotensive at 108/80 mmHg. Physical examination revealed thyroid eye disease and a diffusely enlarged goitre. Electrocardiogram showed atrial fibrillation with rapid ventricular response, and chest radiograph, left lower zone consolidation. Thyroid function test was compatible with thyrotoxicosis [free thyroxine (T4): 57 pmol/L; free triiodothyronine (T3): 12.4 pmol/L; thyroid-stimulating hormone: unrecordable]. The patient was given oral propranolol 20 mg, digoxin 500 mcg and carbimazole 30 mg. However, he suffered a pulseless electrical activity (PEA) cardiac arrest and after 10 minutes of resuscitation, had return of spontaneous circulation (ROSC). Unfortunately, ROSC was not sustained as recurrent PEA arrests ensued. ECMO was unavailable at the managing hospital, and the Extracorporeal Cardiopulmonary Resuscitation team at Singapore General Hospital, an ECMO referral centre was activated. After 4 PEA arrests and 40 minutes of resuscitation, ROSC was precariously maintained on high dose adrenaline (1 mcg/kg/min). Veno-arterial (VA) ECMO was initiated after percutaneous cannulation to facilitate a safe transfer to Singapore General Hospital.

The patient subsequently suffered downstream complications of prolonged cardiac arrest, i.e., ischemic hepatitis, acute kidney injury requiring renal replacement therapy, and disseminated intravascular coagulopathy. He was treated with esmolol infusion, hydrocortisone 100 mg 6 hourly and cholestyramine 4mg 8 hourly while targeted temperature management at 36 °C was maintained for 24 hours. As thioamides were precluded by severe hepatic dysfunction, he underwent plasmapheresis with rapid clinical and biochemical stabilization after 3 days (T4: 22 pmol/L; T3: 6.0 pmol/L). ECMO speed was set at 3,385 rpm achieving a flow of 3.7 to 4.2 L/min. Fractional inspired oxygen concentration (FiO2) was set at 100% and the gas sweep speed was maintained at 2 L/min to achieve adequate carbon dioxide clearance and maintain the arterial partial pressure of carbon dioxide of 35 to 40 mmHg. A heparin infusion was used to maintain an activated clotting time of 150 to 200 sec. Haemoglobin levels were maintained between 9.5 to 10.5 g/dL without any need for transfusion. Marked improvement in left ventricular ejection fraction from 20% to 35% facilitated a short 3-day VA ECMO run. On the 3rd day on VA ECMO, a trial of weaning to facilitate was done to facilitate surgical thyroidectomy. ECMO flow was successfully weaned with Noradrenaline support; the cannulas were explanted, and the heparin infusion stopped. Thyroidectomy was performed the following day (Figure 1).The coagulation profile was sent off on the morning preceding surgery and blood products prepared based on the laboratory coagulation tests. His activated partial thromboplastin time (aPTT) was 52.0 sec more than 6 hours after stopping heparin, prothrombin time was 22.5 sec, international normalised ratio (INR) 2.4, platelet levels were 57×109/L and fibrinogen was 0.53 g/L. Thus, 1 litre of fresh frozen plasma, 2 units of cell separated platelets, 10 units of cryoprecipitate were transfused prior to incision. In the operating theatre, a rotational thromboelastometry was performed which showed an EXTEM A10 of 33 mm, and FIBTEM A10 of 6 mm, thus another 10 units of cryoprecipitate was given intra-operatively. Adequate surgical haemostasis was confirmed with a Valsalva manoeuvre prior to closure. Post procedure, the INR remained below 1.5, aPTT remained less than 1.5 times the upper limit normal, fibrinogen remained above 1 g/L and platelets remained above 50×109/L without any further transfusion. Postoperatively, sinus rhythm was restored, and levothyroxine started as T3 level had fallen below normal. However, the patient remained comatose. Equivocal clinical findings (preserved pupillary/corneal reflexes but absent motor response) rendered neuroprognostication challenging and ancillary testing necessary. The presence of thyroid eye disease with resultant divergent gaze also confounded our findings (Figure 2). Brain magnetic resonance imaging revealed preserved grey-white differentiation, and electroencephalogram was consistent with severe diffuse encephalopathy (maximum bi-frontal bursts, generalized suppression). Due to insufficient predictive evidence of a poor neurological outcome, tracheostomy was planned for the patient in the interim. The derangements from presumptive metabolic encephalopathy (ammonia: 228 µmol/L; urea: 10.4 mmol/L)were managed with lactulose and RRT while awaiting neurological improvement. On the day that he was due for tracheostomy, the patient regained full consciousness (Glasgow Coma Scale 15) and was promptly liberated from mechanical ventilation. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient.

Figure 1 Post-thyroidectomy scar.
Figure 2 (A) Thyroid eye signs showing deviation of gaze front view; (B) thyroid eye signs side view.

Patient perspective

The patient was grateful for the care he received and felt fortunate to be alive. However, he feels tired easily, requiring assistance with and unable to do many of the activities he could do for himself prior to his illness.


Discussion

Thyroid storm is a rare, life-threatening condition associated with multi-organ dysfunction and high mortality rate. It may be precipitated by an acute event such as trauma, surgery, infection, or non-compliance to medication. A multimodal approach is recommended which involves blockage of thyroid hormone production, symptom control and organ support in an intensive care unit (ICU) (9). There is insufficient evidence for the routine use of plasma exchange as first line therapy for management of thyroid storm. However, in cases where anti-thyroid medications are contraindicated or where first line treatment have failed it has been successfully used (10,11). It has also been used to achieve rapid symptomatic control of thyrotoxicosis prior to definitive surgical treatment (12). A significant proportion of patients with thyroid storm have cardiovascular symptoms even leading to cardiovascular collapse. Extracorporeal membrane oxygenation (ECMO) is now a well-established, lifesaving option for patients with acute cardiorespiratory failure (1).

As thyroid cardiomyopathy is potentially reversible, VA ECMO could rescue circulatory collapse and bridge the patient to improvement or recovery of cardiac function while other treatments are ongoing. The successful use of ECMO in patients with thyrotoxic cardiomyopathy, and the feasibility of performing plasmapheresis on ECMO have been reported (4,6,7,13,14). However, to our knowledge, this is the first reported case of combining the use of both VA-ECMO, and plasma exchange as a bridge to urgent thyroidectomy in an extreme case of thyroid storm.

Neuro-prognostication following significant CPR downtime is difficult in the presence of confounding metabolic abnormalities and multi-organ dysfunction. A more thorough workup using a combination of clinical signs, biochemical tests, electrophysiological assessment, and brain imaging is warranted in such cases. Good functional recovery post circulatory collapse is dependent in several factors including good quality CPR, aggressive targeted temperature management and early initiation of ECMO for circulatory collapse.


Conclusions

VA ECMO and plasmapheresis are temporizing measures to bridge to definitive thyroidectomy in thyroid storm management. This case illustrates the importance of expediency in instituting the stepwise treatment modalities in a time-sensitive manner that led to a favourable outcome.


Acknowledgments

The case has been presented in part as a poster at the CHEST World Congress, Thailand in 2019. All authors played an active role in management of the patient in the intensive care unit.

Funding: None.


Footnote

Reporting Checklist: The authors have completed the CARE reporting checklist. Available at http://dx.doi.org/10.21037/jeccm-20-147

Peer Review File: Available at http://dx.doi.org/10.21037/jeccm-20-147

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at http://dx.doi.org/10.21037/jeccm-20-147). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.


References

  1. Extracorporeal Life Support Organization. ELSO Guidelines for Cardiopulmonary Extracorporeal Life Support. Ann Arbor, MI, USA [Internet]. 2017;(August):1–26. Available online: https://www.elso.org/Resources/Guidelines.aspx
  2. Hsu LM, Ko WJ, Wang CH. Extracorporeal Membrane Oxygenation Rescues Thyrotoxicosis-Related Circulatory Collapse. Thyroid 2011;21:439-41. [Crossref] [PubMed]
  3. Chao A, Wang CH, You HC, et al. Highlighting Indication of extracorporeal membrane oxygenation in endocrine emergencies. Sci Rep 2015;5:13361. [Crossref] [PubMed]
  4. White A, Bozso SJ, Moon MC. Thyrotoxicosis induced cardiomyopathy requiring support with extracorporeal membrane oxygenation. J Crit Care 2018;45:140-3. [Crossref] [PubMed]
  5. Genev I, Lundholm MD, Emanuele MA, et al. Thyrotoxicosis-induced cardiomyopathy treated with venoarterial extracorporeal membrane oxygenation. Heart Lung 2020;49:165-6. [Crossref] [PubMed]
  6. Kim S, Seol SH, Kim YS, et al. Thyrotoxicosis induced cardiogenic shock rescued by extracorporeal membrane oxygenation. J Geriatr Cardiol 2018;15:203-4. [PubMed]
  7. Allencherril J, Birnbaum I. Heart Failure in Thyrotoxic Cardiomopathy: Extracorporeal Membrane Oxygenation Treatment for Graves’ Disease. J Extra Corpor Technol 2015;47:231-2. [PubMed]
  8. Eyadiel L, Amjad A, Pisani B, et al. Use of Therapeutic Plasma Exchange and ECMO Support with Impella for LV Vent as Treatment for Cardiogenic Shock in Acute Thyrotoxicosis/Thyroid Storm. J Card Fail 2018;24:S84-5. [Crossref]
  9. Ross DS, Burch HB, Cooper DS, et al. 2016 American Thyroid Association Guidelines for Diagnosis and Management of Hyperthyroidism and Other Causes of Thyrotoxicosis. Thyroid 2016;26:1343-421. [Crossref] [PubMed]
  10. Schwartz J, Padmanabhan A, Aqui N, et al. Guidelines on the Use of Therapeutic Apheresis in Clinical Practice-Evidence-Based Approach from the Writing Committee of the American Society for Apheresis: The Seventh Special Issue. J Clin Apher 2016;31:149-62. [Crossref] [PubMed]
  11. Muller C, Perrin P, Faller B, et al. Role of plasma exchange in the thyroid storm. Ther Apher Dial 2011;15:522-31. [Crossref] [PubMed]
  12. Ezer A, Caliskan K, Parlakgumus A, et al. Preoperative therapeutic plasma exchange in patients with thyrotoxicosis. J Clin Apher 2009;24:111-4. [Crossref] [PubMed]
  13. Kiriyama H, Amiya E, Hatano M, et al. Rapid Improvement of thyroid storm-related hemodynamic collapse by aggressive anti-thyroid therapy including steroid pulse: A case report. Medicine (Baltimore) 2017;96:e7053 [Crossref] [PubMed]
  14. Dyer M, Neal MD, Rollins-Raval MA, et al. Simultaneous extracorporeal membrane oxygenation and therapeutic plasma exchange procedures are tolerable in both pediatric and adult patients. Transfusion 2014;54:1158-65. [Crossref] [PubMed]
doi: 10.21037/jeccm-20-147
Cite this article as: Wong IMJ, Lim JY, Goh JTK, Tan QL, Tay CK. Thyroid storm rescued by extracorporeal membrane oxygenation support, plasmapheresis and thyroidectomy: a case report. J Emerg Crit Care Med 2021;5:19.
